Iso-Mount acoustic ceiling hangers
Our unique Oscar Iso-Mount acoustic hanger systems are engineered to deliver exceptional ceiling soundproofing without compromising ceiling height or aesthetics. Designed with both performance and practicality in mind, Iso-Mount combines space-saving with high-performance acoustic isolation.
Independently tested at BRE, the system not only exceeds the requirements of Building Regulations Part E for for airborne and impact sound, but also achieves up to a 90-minute fire rating in the tested configuration—ensuring robust, regulation-compliant protection for residential and mixed-use developments.
acoustic hanger projects
frequently asked questions
Acoustic hangers create suspended ‘floating’ ceilings, significantly reducing noise transfer between floors by absorbing vibrations and sound pressure waves generated by footsteps, music or voices from the room above.
Type1 – Fix the ‘L’ Bracket to the side of the timber joist with two 4x30mm screws.
Type2 – Fix the ‘C’ Bracket to the underside of the timber joist with one 5x60mm domed Pozidrive screw and 5mm cup and penny washer.
Or
Type2 – Fix the ‘C’ Bracket to the underside of the Concrete ceiling with one 7.5x50mm Easydrive concrete screw.
Or, when extensions are used, fix to the underside of the Concrete ceiling with one M8 concrete socket bolt.
When the ‘L’ or ‘C’ brackets are fixed, the rubber isolating block and saddle simply push fit into place.
