features of SonaSpray K-13 acoustic spray
- Achieves M1 certification for Building Materials emissions.
- Class 0 to BS476 & B-s1,d0 fire rating (full fire test reports available on request). View full fire ratings.
- Excellent noise reduction in buildings by absorbing sound energy instead of reflecting it thereby reducing reverberation times & overall noise levels.
- Can contribute up to 17 points to the overall Leadership in Energy & Environmental Design (LEED) rating of a project.
- Product-Specific, Environmental Product Declarations (EPDs) to ISO 14025 available. See related PDFs.
- Acoustic spray can be applied to virtually any configuration of substrate.
- The adhesive provides a resilient bond that is strong & durable.
- Can aid in condensation control by inhaling and exhaling moisture as the indoor climate changes.
SonaSpray K-13
technical specifications
Our SonaSpray range exceeds the latest fire requirements set under the updated Fire Safety: Approved Document B.
European fire test by Efectis Nederland:
B – s1, d0
UK fire test by Warrington fire research:
Class 0 to BS476 Part 6
Class l to BS476 Part 7
Full fire test reports available on request.
Important Note: Always insist on obtaining a copy of the fire test report before using a product.
Its Class 0 to BS476 and B-s1,d0 fire rating provide significant benefits over the new Approved Document B requirements by providing little to no smoke and absolutely no droplets, assisting in the safe escape of occupants. Click here for more information on the fire properties of SonaSpray and the new Approved Document B requirements.
SonaSpray K-13 can be tailored to meet your specific project acoustic needs. There is a choice of finish and you can select texture, colour and acoustic performance. SonaSpray K-13 can be applied at variable thickness and variable areas to provide a designed acoustic ambience. It is spray applied to the full thickness in one application.
For the ultimate acoustic combination in sports halls, use SonaSpray K-13 on standard plain non-perforated deck with the new Oscar Evo-Panel at low level. The Oscar Evo-Panel is the first acoustic panel designed specifically for use at low level in high impact areas. Positioning these at low level prevent sound flutter off lower walls meaning you require 35% less Evo-Panels than standard acoustic panels at high level. Sport England compliant.
“Changing spec from standard acoustic panels at high level and replacing perforated metal deck in our sports hall with plain galvinised metal deck treated with SonaSpray K-13 has saved us a fortune & time in the programme. Everyone has commented on how quiet the sports hall is now”.
A large well known Main Contractor.
| Depth | 125Hz | 250Hz | 500Hz | 1kHz | 2kHz | 4kHz | NRC | αw |
|---|---|---|---|---|---|---|---|---|
| 16mm | 0.10 | 0.40 | 0.90 | 0.95 | 1.00 | 1.00 | 0.85 | 0.70 |
| 25mm | 0.20 | 0.55 | 0.95 | 1.00 | 1.00 | 0.95 | 0.90 | 0.85 |
| 38mm | 0.20 | 0.65 | 1.00 | 1.00 | 1.00 | 1.00 | 0.95 | 0.95 |
| 50mm | 0.35 | 0.80 | 1.00 | 1.00 | 1.00 | 1.00 | 0.95 | 1.00 |
| 70mm | 0.40 | 1.00 | 1.00 | 1.00 | 1.00 | 1.00 | 1.00 | 1.00 |
| 76mm | 0.50 | 1.00 | 1.00 | 1.00 | 1.00 | 1.00 | 1.00 | 1.00 |
Test DATA certified by TNO Technical University Delft NL. Tests were on a solid backing. A panel backing with air space behind the panel will change absorption; normally there is improved absorption at low frequency. Substrates likely to provide increased performance include plasterboard with the use of an air gap behind, rib deck or profiled metal sheet. Please contact Oscar Acoustics’ technical department for free assistance.
Ideal for rain noise reduction.
The SonaSpray range contributes towards many sustainable design and health certification systems including BREEAM, SKA, Living Building Challenge and adds up to 17 points towards the LEED (Leadership in Energy and Environmental Design) rating of a project.
The SonaSpray range achieves M1 certification as Low Emitting Building Materials. This is the best possible classification.
View M1 emissions classification certificate
SonaSpray finishes are compliant with CDPH/ CA Section 01350 and are GREENGUARD Gold Certified for Indoor Air Quality. GREENGUARD Gold Products are now confirmed to show compliance with BREEAM rating system HEA Indoor Air Quality and ensure that a product has met some of the world’s most rigorous and comprehensive standards for low emissions of VOC’s into indoor air. The range is also covered by an Environmental Product Declaration in accordance with ISO 14025 and meets the requirements of the Living Building Challenge and LEED.
Achieves Cradle2Cradle and contributes towards satisfying many features under the WELL Building Standard®.
Made of fire treated, recycled paper and other rapidly renewable natural resources, SonaSpray can effectively lower the carbon footprint of the building project by sequestering rich stores of carbon for the life of the structure or application.
Oscar Acoustics have taken steps to reduce our environmental impact and demonstrate our commitment to protecting the environment by achieving ISO 14001 certification.
ISO 9001: 2000 certification
- SonaSpray is manufactured by ICC to ISO 9001.
- Installed using a four stage Oscar Acoustics quality assurance plan.
Oscar was established in 1978; this experience enables us to provide a well detailed, quality installation that stands the test of time. From specification to installation, everything is kept in-house. Oscar Acoustics only use qualified in-house operatives who specialise in installing our systems to ensure high standards are maintained.
- BIM Objects available for every product.
- All products are included within all current NBS software.
- Recessed and surface mounted items possible – see website for more information.
- Standard detail drawings for most situations.
- Bespoke detailing solutions possible.
SonaSpray insulates by creating dead air spaces macroscopically between and within the hollow cellulose fibres. Testing on actual buildings demonstrates that sprayed insulation outperforms fibreglass batts that are mechanically retained. 100mm thick U = 0.32 W/m2K.
For areas such as indoor pools and ice arenas, SonaSpray K-13 aids in condensation control. The proper combination of SonaSpray K-13 and ventilation prevents condensation on metal, concrete and other surfaces. SonaSpray K-13 reduces ventilation requirements, saving in both the ventilation equipment investment operating costs.
- Dry Weight of SonaSpray K-13 per 10mm thickness = 0.72 kg/m2
- Wet Weight of SonaSpray K-13 per 10mm thickness = 1.37 kg/m2
- Dry Weight of SonaSpray K-13 per 20mm thickness = 1.44 kg/m2
- Wet Weight of SonaSpray K-13 per 20mm thickness = 2.74 kg/m2
SonaSpray K-13 noise reduction insulation can be applied to virtually any substrate; some surfaces may need priming to control suction. Old surfaces may need a barrier coating to prevent staining from leaching out contaminants whilst the surface is wet.
Standard Colours: (s) = Stock (ns) = Non-Stock
SonaSpray fcx: Arctic White (s), White (ns)
SonaSpray fc: Arctic White (s), White (ns), Black (ns)
SonaSpray K-13 Special: White (s), Light Grey (s), Grey (s), Dark Grey (ns), Black (s), Beige (ns), Tan (ns)
SonaSpray K-13: White (s), Light Grey (s), Grey (s), Dark Grey (ns), Black (s), Beige (ns), Tan (ns)
Bespoke colours are manufactured to order. Minimum order quantities apply and square meterage is dependent on the product and thickness of spray. Please send us your colour requirement using a Dulux paint reference and we will respond with quantity, price and colour samples.
The adhesive used with SonaSpray K-13 noise reduction insulation provides a strong, durable and resilient bond. When fully cured, surface strength of old plaster will typically improve. Fully cured SonaSpray K-13 can improve strength.
Recessed services e.g. spot lighting will require a halo spacer to match the material depth. Oscar Acoustics manufacture and install stainless steel halo spacers (drawing available) to the same size as the hole cut out. Stop beads may be required around openings which again we can supply and install. Specially designed access hatches are also available through Profab, enabling the SonaSpray to continue across the hatch door. Problems can arrise from using other hatches. These items are at extra cost and are to be purchsed direct from the Profab. Please contact Oscar Acoustics for details and item code. Surface mounted fittings e.g. hanging/pendant lights will require pattresses to match the material depth. Please contact Oscar Acoustics for further advice.
Please Note: 90% of flangeless fittings do not work properly with any acoustic finish. If you are specifying a flangeless fitting, please contact Oscar Acoustics for advice.
SonaSpray K-13 noise reduction insulation can be quickly and effectively applied to any prepared surface and construction configuration. This allows minimum working down time in existing structures with abilities to meet critical deadlines in new construction. SonaSpray K-13 has a coarse surface texture and is suited to large buildings with longer viewing distances; or use close up where a strong texture is required. Other SonaSpray products offer a finer surface texture. SonaSpray K-13 is also ideal in some cases for rain noise reduction within the building.
Please note that it is important not to use moisture resistant plasterboard as this can cause staining of wet applied products. Oil based stain barrier paints can be used to prevent this. Please consult Oscar Acoustics for more information.
A minimum of 12.5mm thick plasterboard, installed to British Gypsum specification should be used.
USA – Factory Mutual Standards research corp. approvals: category I, II, III, IV and V:
| ategory_I | As an interior finish material of low fire hazard [class I building material] over non-combustible surfaces not requiring automatic sprinkler protection in and of itself. |
|---|---|
| Category_II | As a protective coating to delay the ignition and reduce the surface burn rate of combustible wood and cellulosic fibre building material. |
| Category_III | As a protective coating to delay the ignition and reduce the surface burn rate of low melting point, combustible cellular plastic building materials and to protect their dimensional stability for a brief period. |
| Category_IV | As a protective coating for building structural steel, to supplement automatic sprinkles protection in preventing structural failure temperatures of the steel in high fire hazard occupancies. |
| Category_V | As a protective coating to the underside of a Class II insulated steel roof deck construction, to sufficiently lower the rate of fuel contribution from the Class II deck components to qualify the construction as Class I so allowing automatic sprinkler protection to be omitted under Factory Mutuals Standards. |
SonaSpray K-13 noise reduction insulation can be over-painted or applied with additional coats of SonaSpray. Small areas of damage can be repaired by hand.
If SonaSpray K-13 is disturbed or damaged so that fibre is released into the atmosphere, the resulting contamination is harmless. Maintenance work can be undertaken while the building is occupied. Please refer to COSHH data for detailed product analysis.
Please fill out your details below to access our image packs.
You will need Adobe Acrobat Reader to view them.
SonaSpray K-13 vs. Sprayed Fiberglass VIDEO – a comparative fire endurance test
This test was conducted to evaluate the fire performance and endurance qualities of two different spray applied materials used as exposed thermal and acoustical finishes. The test materials were SonaSpray K-13, a cellulose material, and sprayed fiberglass. The test was conducted using the ASTM E-119 Standard for Fire Tests of Building Construction and Materials.
variety of acoustic spray colours available
Available in a range of standard colours from stock, SonaSpray K-13 acoustic spray can also be specially manufactured to the client’s colour requirement (minimum quantity applies).
SonaSpray K-13 is a total system with in-built treatment for fire and mould resistance and has colouring throughout the full thickness of the coating.
Future reconstruction of buildings may require removal of acoustic spray. SonaSpray can be recycled or disposed of as a non-special waste and your local authority waste disposal will be able to give advice on recycling.
- Carbon neutral.
- Low embodied energy.
- Good for the environment and recyclable.
- Safe, recycled, natural cellulose fibre.
